The present invention discloses a nitrogen and air compressor with multiple compression stages. The compressor comprises a crankcase, a crankshaft, a connecting rod, a Gudgeon pin, a plurality of piston, a plurality of cylinders, a plurality of scraper rings for a first and a second compression stage, a flywheel ada...

The present invention introduces a concept of flow distributor. Flow distribution using flow distributor is novelty of this invention. When the existing shell & tube heat exchanger is possible to be replaced with two or more smaller shell & tube replacement heat exchangers with shell side flow divided in the two or ...

The present invention discloses an air compressor assembly with high pressure capacity. The compressor assembly comprises a multistage compressor, a prime mover, a lubrication mechanism, an inter-stage cooler, a condensate drain mechanism, a plurality of filters, a plurality of interconnecting pipelines, an air drye...

The present invention discloses a trailer mounted compressor apparatus for providing combined facility of generating, compressing, storing and real-time distributing air and nitrogen on a site. The apparatus comprises an air-suction means, a compression assembly, a plurality of filters, a dryer, a plurality of after...

The various embodiments of the present invention disclose a biogas compressor assembly combined for raw as well as refined biogas. The compressor assembly comprises a plurality of booster increases a pressure of the refined biogas upto 250 and allows a flow rate capacity upto 40  The compressor assembly is arranged ...

The embodiments of the present invention provide a condensate cooling apparatus for a compressor to improve an air-oil mixture cooling. The apparatus comprises a condensate housing, a condensate pipe and a flow monitor. The condensate housing encompasses an air-oil mixture pipe. The condensate housing comprises a...

The invention relates to a method of simultaneous surge detection and surge control in a centrifugal compressor using a PID control, blow off valve, inlet guide vane, auxiliary oil pump, current input, pressure input, etc. When the system pressure is lower or higher than the set pressure, the system indicates on the...

The embodiments of the present invention provide a rotor assembly in a screw compressor with a homotopic rack profile comprising a main rotor and a gate rotor. A teeth profile of the leading edge of the main rotor and a trailing edge of the gate profile is created to intersect with the homotopic rack profile. ...

ENCLOSURE FOR SCREW COMPRESSOR WITH EFFICIENT COOLING MECHANISM ABSTRACT The various embodiments of the present invention provide an enclosure for a screw compressor comprising an air inlet unit, a cooling unit and a baffle unit. The air inlet unit comprises a suction box, and air filter and is fitted to an enc...

ABSTRACT The various embodiments of the present invention provide a rotary screw air compressor comprising a suction unit, a compressor with a discharge unit. The suction unit comprises a multi-axial suction port. The compressor with the discharge unit is flanged to the suction unit and comprises a pair of rotor...

ABSTRACT “A CENTRIFUGAL COMPRESSOR” The present disclosure relates to a centrifugal compressor (100). The centrifugal compressor (100) comprises a compressor casing (102), a motor casing (104) and a 5 power electronics unit (103). The motor casing (104) comprises a motor assembly (106) and at least one magnetic be...

ABSTRACT [0030] The present invention relates to a reciprocating air compressor arrangement which is used for water-cooled air compressor models with canopy to deliver the compressed air. A suction filter is placed above the 1st stage cylinder of the compressor bare by which fresh air from the atmosphere enters the ...

ENCLOSURE FOR STANDARDISED BELTGUARD FOR RECIPROCATING AIR COMPRESSOR ABSTRACT [0039] The present invention relates to beltguard (1) and provides for length adjustment according to variation in the centre distance between electric motor (5), electric motor pulley (8) and flywheel (9). The beltguard (1) is split int...

ABSTRACT [0039] The present invention relates to beltguard (1) and provides for length adjustment according to variation in the centre distance between electric motor (5), electric motor pulley (8) and flywheel (9). The beltguard (1) is split into 3 subassemblies, whereby assembly and dismantling of beltguard (1) be...

This invention introduces a cutting-edge system designed to enhance the efficiency and performance of multi-stage screw compressors. By integrating traditional physics-based models with modern machine learning techniques, the process optimizes key operational parameters, minimizes energy consumption, and improves ov...

ABSTRACT Adaptive Radial Clearance Control in Screw Compressors Using Shape Memory Alloy-Enhanced Rotor Casing. The invention relates to an adaptive clearance control system for screw compressors utilizing Shape Memory Alloys (SMAs) embedded within the rotor casing. The SMA elements are configured to deform in respo...

ABSTRACT MULTIPLE ANTI FRICTION CYLINDRICAL ROLLER BEARING ARRANGEMENT IN GAS SCREW COMPRESSOR. The present invention relates to a bearing arrangement for screw compressors, designed to efficiently manage high radial loads. Conventional screw compressors use either single large antifriction bearings or journal beari...

1 INTEGRATED BEARING IN A BEAVEL GEAR FOR IGV CONTROL IN A CENTRIFUGAL COMPRESSOR ABSTRACT The embodiments of the present invention provide an integrated assembly of a bevel gear and a bearing housing in a centrifugal compressor to provide a frictionless motion transfer to an inlet guide vane. The assembly comprises...

Guide Ring-Assisted Hydraulic Piston for Capacity Control in Refrigeration Screw Compressors ABSTRACT The present invention relates to an improved hydraulic piston-cylinder arrangement for refrigeration screw compressors, incorporating guide rings to enhance precision, reduce wear, and improve operational efficiency...
