[025] The present invention discloses a circuit for a common mode rejection, wherein the circuit includes a capacitive divider network coupled to at least two outputs of a multi-channel multiplexer (MUX). The capacitive divider network includes at least two capacitors coupled in parallel to the at least two outputs ...

A structure (10) of a waveguide rotary joint to enable communication through a plurality of channels is provided. The structure includes a first wave guide (20) to receive radio waves from a radio source. The structure includes telescopic tubes coupled to the first wave guide. The telescopic tubes includes a conduc...

A radio frequency (RF) slip ring (100) is disclosed. The RF slip ring includes an outer assembly (102) that includes a flange (106) to accommodate the RF contact (108) to transfer maximum RF signal power with minimal loss. The RF contact is a structure combining a spring and RF power divider (114) and disposed on a ...

A method (10) to improve a plurality of material properties of an electrical joint is provided. The method includes providing a first layer of coating on the electrical joint. The first layer of coating includes copper. The method also includes providing a second layer of coating on the first layer of coating. The s...

A contactless radio frequency (RF) rotary joint (100) is disclosed. The contactless RF rotary joint includes a circular structure (102) with a hollow central bore (104). The circular structure includes a circular ring (106), a shielding surface (110), and a dielectric medium (112). The circular ring is positioned on...
