The present invention relates to an improved process for manufacturing of foamed door with foamed-in lock assembly. In the process of the present invention  barrel of lock assembly is pivotally mounted on the front (rigid) panel and a guider is mounted on the rear (flexible) panel for receiving the said barrel. The ...

A process for the manufacture of substrate for powder coating of the galvanised sheet for use in a refrigeration appliance comprising a two stage process of degreasing and rinsing. The process involves two pair of tanks. Tank I & II contains the solution of Iron Phosphate and demineralized water in a particular temp...

The present disclosure relates to a system for detecting or sensing load change incorporated in a refrigerating unit (R) wherein an ambient sensor (3) senses the load change or temperature of the condenser tube (14) of refrigerating unit (R). Whenever a load change occurs due to opening of a door (15) of the refr...

The present invention relates to refrigerator with an integrated sliding bottom drawer, which can store the vegetables. It comprises of three major components Fascia, base and tray that can be assembled to make the whole component. It can be easily fitted with a refrigerator and can withstand its load even while dra...

A baffle tray comprising a pair of ribs provided at the rear left and right side of the baffle tray, a pair of roller protruding out of the baffle tray conforming to the cavity of the ribs press fitted on to the said ribs providing free and smooth movement of the baffle tray outwardly and inwardly, cabinet linear gu...

The present invention relates to a quick ice making unit/assembly/arrangement, comprising: an ice container made of a material having high thermal conductivity to freeze the water contained therein faster; a holder/stand for holding/supporting the ice container; plurality of /channels formed at the bottom of the ice...

Present invention relates to a refrigerator having a water dispenser system. The refrigerator comprising a storage tank placed inside the refrigerator, wherein the storage tank comprises a modular structure to store water at an optimum temperature; a dispensing system placed outside the refrigerator, wherein the dis...

A refrigerator comprising a dispensing unit has been disclosed, wherein the refrigerator comprising: a storage tank, placed in the interior of the refrigerator; a dispensing unit placed in the exterior of the refrigerator, wherein the dispensing unit configured to include a plurality of outlet; and a connecting asse...

PLEASE SEE THE ATTACHED SPECIFICATION.

PLEASE SEE THE ATTACHED SPECIFICATION.

PLEASE SEE THE ATTACHED SPECIFICATION.

The present disclosure relates to a refrigerator. The refrigerator has a refrigerating compartment and a freezer compartment, an incoming air passage, comprising of a first opening on an outer wall of the refrigerator and a second opening in a heat exchanger of the refrigerator. The incoming air passage comprising: ...

The present invention provides a suitable mechanism for reducing excessive temperature of a compressor in an air conditioning system. More particularly, the present invention provides a mechanism for forced circulation of air inside the compressor chamber. The compressor chamber of an air conditioner comprises of...

The present invention discloses a direct drive washing machine which has a washing capacity as large as possible by effectively using the space between the casing and the outer tub without increasing the size of the casing. More particularly  the present invention provides a direct drive washing machine comprising a...

A detergent dispenser assembly of a washing machine comprises a base member, wherein the base member is connectable to the washing machine. A detergent dispenser tray is configured with plurality of slider arms, wherein each of the plurality of slider arms is configured with at least one protrusion. At least one dam...

The present invention provides a packaging system for appliances used in homes, small shops and offices. The system is easy to use, made of environmentally friendly materials, and doesn’t pose operational hazard or harm to people or property. The system comprises a box type carton made of cardboard and contains stra...

The present relates to a refrigerator 100. The refrigerator 100 comprises a door panel 102 having four corners 106a-d wherein each of the four corners 106a-d is fitted with a corner cap 104a-d to obtain door panel 102 of desired corner shape.

The present invention relates to a refrigerator 100. The refrigerator comprises a_control board 110, a rechargeable battery 114 elearically coupled with the control board 110 and at least one Light Emitting Diode (LED) board for illumination electrically coupled to the control board 110.

This invention relates to a two phase method for washing clothes in an automatic washer having a wash basket and an impeller located at the bottom, part within the wash basket, the impeller being rotatable about a substantially vertical axis, the method comprising the steps of: loading clothes into the wash basket; ...

The present invention relates to a refrigerator with a vacuum food storage system for food storage and preservation. In one embodiment of the present invention, the system draws air which results in reduction in oxygen molecules and also retains the humidity, thereby maintaining the freshness of the food along with ...

The present invention provides a control 200 for automatically controlling the temperature of a refrigerator 100 according to changing ambient temperature. The control 200 comprises a temperature sensor 110 for measuring the ambient temperature, a main control board 112 coupled to the said temperature sensor 110 for...

The present invention relates to the field of illumination in refrigerators. The consumers face a great inconvenience and discomfort during failure of A. C. mains electrical power supply, when darkness prevails in the interiors of refrigerator and freezer compartments during day or night and in the exterior of refri...

ABSTRACT NOT FILED

A Novel Articles-Holding Device For Refrigerators and a method of using the same Abstract The present invention is in the form of a bottle holder that is used inside any standard refrigerator. The bottle holder of the present invention is attachable to any reasonably flat surface inside the fridge. It allows the c...

A cantilever shelf device for a refrigerator having a pair of guide rail with groove with a self retainer mounted in the each groove which can be slided at any hight in the refrigerator, a self stopper fixed with in each support angle in a pair of support angle, the two flat surfaces on the opposite side of the shel...

The present invention provides a speed control device for a single phase motor used in home appliances comprising an IR source to produce an infra red rays; a motor provided with means for periodically directing infra red rays to generate a sensor output; an IR sensor provided along the path of infra red rays to sen...

A method of cooking food, such as fish and vegetables, using steam during a cooking cycle comprises a preheating step where the cavity is heated toward a cooking temperature and a cooking step where the cavity is maintained at the cooking temperature. The preheating step comprises a dry preheating step where no stea...

The invention provides an apparatus and method for measuring load in washing machine employing speed sensing system using photo-interrupter. The load of clothes in a washing machine is calculated by calculating total inertia of the system. Total inertia of the system can be calculated by measuring line voltage, acce...

The present invention provides an apparatus for washing clothes. The apparatus for washing clothes comprises a container for storing water and clothes, at least one pump driven by a prime mover, the at least one pump being coupled to the said container through one or more suction pipe for re-circulating the water in...

The present invention describes a compressor mounting unit comprising a front support and a rear support to be secured at the rear portion of the refrigerator cabinet for mounting the compressor and supporting the refrigerator cabinet. Each of the front support and the rear support comprises a lowered middle platfo...

The present application relates to multifunctional refrigeration system and method. More particularly, the present application relates to the refrigeration system comprising a combi-zone, wherein the combi-zone may be utilized as a multifunctional space to perform at least one of pasteurization, thawing and steriliz...

The present invention discloses a reverse osmosis water purification system which can reutilize water disposed off the system thereby preventing water depletion problems. In particular  the present invention relates to a reverse osmosis (RO) water purification system for reutilization of disposed water comprising a ...

A lint filter (26) for a washing machine having two or more panels (44, 46, 48) hinged to one another in a series, each panel having a mesh (49) adapted to strain a washing liquid to catch lint in the mesh (49), wherein the panels (44, 46, 48) are foldable over each other to place alternately placed hinge proximate ...

This invention relates to a refrigeration system to extend storage life of refrigerated perishable food like fruit and vegetables, the system comprising: a freezer compartment provided in the upper portion of the refrigeration system; a refrigeration compartment located below said freezer compartment and in air comm...

An improved air conditioning system (100) comprising an evaporator unit (101) connected with a condenser unit (106) in a continuous circuit carrying a refrigerant. The improved air conditioning system comprises a compressor unit (104) for compressing the refrigerant from low-pressure vapor in the evaporator unit ...

The present invention relates to a system for controlling the flow of cold air from the freezer compartment to the food storage compartment of a refrigerator. The system involved the use of a control slide provided within the drip tray of the refrigerator. The sliding movement of the control slide actuates ...

The present invention relates to an improved cooling system for cooling the door bin comprising a tray, a pair of hollow cylindrical ducts having inner projected ends to form an airtight joint attached to the said tray, a hollow cylindrical air distribution pipe, an end plug provided at one of the ends of th...

The present invention relates to a novel faucet coupler assembly having lipseal which can expand in conformity with the size of the tap without tearing and a bulb lock mechanism to rigidly couple the adaptor end.

A stain removing washing machine comprising a wash basket to contain a wash load, an agitator mechanically connected to a motor, a heater for heating said wash load, characterised by: a fuzzy logic circuit configured to cause agitation of said wash load at ambient temperature by oscillating said agitator for...

The present invention relates to the technological field of home appliance devices and the present invention refers to a shelf for house appliances, more specifically for internal cavities of refrigerators, ovens and similar, which cooperates with rails that makes possible its easy and safe slipping for different...

The present disclosure relates to an ice tray for producing faster ice. More specifically, the present disclosure relates to an ice tray which has depressions on its base adaptive to receive the upper protruding portion of evaporator plates arranged in the freezing unit of a refrigerating device. The design of the i...

The present disclosure relates to a refrigerator (1) comprising a cabinet (2) having at least one door (4) to provide access to one or more storage compartment. A liquid dispenser unit (5) being placed in the door (4) wherein the liquid dispenser unit (5) comprises an inlet tube (8) configured to receive liquid f...

The present invention is directed to an automatic-defrost voltage stabilizer for automatically defrosting a refrigerator connected to said voltage stabilizer and at the same time providing a regulated voltage supply to the refrigerator. The automatic-defrost voltage stabilizer comprises a co...
