This invention relates to a structure mounting bracket assembly for automobile comprising a plurality of brackets including second bracket interposed between first and third bracket constituting a single structure wherein the first bracket receives inclined part of rear floor frame and the third bracket is in con...

This invention relates to a novel emblem mouriting for a vehicle to diffuse emblem reflection comprising of a reflector mounted with a lens provided with emblem, which is fitted on to body of vehicle, wherein back surface of the lens is provided with etching. The invention is associated with the following advant...

This invention relates to weld overflow detection device for Hub mounting plate of vehicle comprising a longitudinal member mounted with a guide pin at an intermediate point of the longitudinal member. It is associated with the following advantageous features: - Simple in construction. - Facilitates checking op...

The present subject matter disclose a seat cover (300) having a fastening assembly for attaching the seat cover (300) to seat pad. The present seat cover (300) has a plurality of stretchable band/fabric fasteners (302). Each of the plurality of stretchable band/fabric fasteners (302) has circular holes at both ends ...

This invention relates to an integrated mounting bracket for bowden cable in motor vehicle comprises a member secured to a holder at both ends, which includes a bigger holder and a smaller holder. It is associated with the following advantageous features: - Easy assembly of cable into integrated bracket - Less ...

This invention relates to novel arrangement for CNG pressure gauge in vehicle comprising of a receptacle having filling valve for refueling connected to a pressure regulator through a valve integrated CNG tank by means of high pressure pipe, in which the regulator integrated with a high pressure lock off valve an...

This invention relates to an automobile window regulator system for operating side door window glass comprising a long screw mounted with a nut. fastened to a connecting plate engaged with a carrier plate, which is connected to the window glass. It is associated with the following advantageous features:- - Simple ...

This invention relates to a dust cap for actuation of micro-switch wherein contact material with said micro-switch is a metal for withstanding high contact pressure and the holding area is non metallic.

This invention relates to a dust cap for CNG filler valve inside the engine room wherein contact material with said micro-switch is a metal for withstanding high contact pressure and the holding area is non metallic in which said dust cap is provided with a tether.

This invention relates to a side sill of vehicle comprising of a side sill outer and a side sill inner facing each other, wherein the side sill outer having a longitudinal hollow member with one open side provided with a number of holes with mounting structure which are symmetrical on both sides of the side sill out...

This invention relates to an improved and integrated vent ducts for CNG and LPG systems comprising of twin ducting for venting atleast two holes on single vent duct and a snap fit type of locking for mounting onto the floor.

This invention relates to a connecting rod for internal combustion engine of vehicle, small end of which is connected to piston pin of piston and big end of which is· connected to crankshaft of engine block, wherein the big end is provided with a hole on one side facing thrust side of piston for lubrication and anot...

This invention relates to instrument panel of vehicle for interchangeability of passenger air bag, upper utility box and dummy cover of air bag and utility box for various variants comprising a. frame having a plurality of openings for accommodating air bag covered by means of a cover and upper utility box, which a...

This invention relates to an assembly of cover instrument panel driver/ assistant driver side and ornament instrument panel centre lower in automobile comprising instrument panel centre lower, each mating surface of which is integrated to a protruded part and snap placed opposite to each other for engagement with ...

The present invention relates to molded roof lining of vehicle comprising a single structure having a deep draw on both sides in longitudinal direction thereof wherein aft edge of the roof lining includes a curved part extended towards back panel of vehicle.

This invention relates to a rubber bushing with variable stiffness in automobile suspension comprising a cylindrical structure having resilient material part interposed between inner and outer metallic sleeve, wherein the resilient part is provided with variable thickness in different directions. It is associat...

The present invention relates a instrument panel (IP) wiring harness protector (100, 200, 400) for protecting instrument panel (IP) wiring harness in vehicle. The IP wiring harness protector (100, 200, 400) includes a flap portion (102, 406) and a body portion (408). The flap portion (102, 406) is to receive the IP ...

The present subject matter relates to assembly of inner part of panel instrument cluster (part 1) with outer part of the panel instrument cluster (part 2) from rear side of the instrument panel of vehicle.

This invention relates to an improved cylinder head gasket to improve the sealing in exhaust side oil return gallery disposed between cylinder head and cylinder block wherein said cylinder head gasket comprising of a plurality of oil return galleries provided with resilient material coated metallic grommets on t...

This invention relates to an arrangement of air intake system and radiator for diesel engine vehicle comprising an air cleaner mounted on engine with intercooler placed on left hand side and radiator and fan assembly located on right hand side of engine. It is associated with the following advantageous features:- ...

This invention relates to radiator support bracket for vehicle comprising a single structure including two substantially horizontal members with a curved member therebetween maintaining difference in level between said horizontal members with mounting holes. It is associated with the following advantageous features...

ABSTRACT "A lining used for mounting on a mating part of vehicle" This invention relates to a lining used for mounting on a mating part of vehicle comprising a lining member integrally provided with a mounting structure around the mounting area for assembling the lining with the mating part of vehicle at the mo...

The present invention relates to a single structured cushion clip for vehicle comprising of cushion body integrated to clip body constituting an elongated structure made of a· single material. It is associated with the following advantageous features:- -Involves one step process. -Cost effective. -Easy manufact...

The present invention relates to a system and method for automatically creating gear shift assembly design, wherein, obtaining input data representative of hip (H) point, knob point, ball point, shift parameters, select parameters, point P1 parameters, lever angles, select finger, bell crank arm, steering points, mo...

A slit structured dash silencer (100) for an automobile is disclosed. The slit structured dash silencer (100) including a plurality of slits (102); and a plurality of flaps (104) defined through the plurality of slits (102), wherein the plurality of flaps (104) are configured to move away from the dash silencer (100...

This invention relates to a reinforcement for fuel filter on battery tray of vehicle wherein said tray is having multitude of vertical panels including a back panel and atleast two side panels connected to each other, out of which one side panel is mounted with fuel filter holder for fuel filter, wherein said reinfo...

The subject matter disclosed herein relates to a structure of hood cross member (400) with optimized bead structure (402) for improving the radiator mounting and reducing the radiator mounting bracket vibrations performance in a vehicle. The optimized bead structure (402) is provided at the weakest location to impro...

The present subject matter relates a structure of an instrumental panel (1) for a vehicle to absorb shock during impact or head collision. The structure for the instrumental panel (1) includes a central louver garnish (3) which is clip mounted on the instrumental panel (1). The structure further comprises a rib str...

The subject matter relates to a mounting structure (300) between grip door handle and door panel assembly (307) of the vehicle to absorb the impact force during the 5 side impact. In the present mounting structure, a bracket (305) is mounted between the grip door handle and the door panel assembly. The bracket (305)...

The present invention relates a passenger side air bag (PAB) mounting structure 5 for un-obstructed access to screw mounting (501, 701) of PAB housing (506) mounted on instrument panel (403) from glove box opening (404) of vehicle. The passenger side air bag (PAB) mounting structure comprises the PAB housing which h...

The present invention relates a mounting structure for an electronic control unit (ECU) in engine compartment of the vehicle to give the best possible location of ECU (107) in the engine compartment, so that assembly and de-assembly time required at the time of manufacturing and service is reduced. Also, to reduce t...

The present subject matter relates to driver side pocket structure having rib structure in the Switch bezel under the steering wheel of the vehicle. Further, ribs on cover to be mounted on the pocket structure are engaged with the ribs present on the pocket structure. The engaged portion of the ribs removes vertica...

This invention relates to multifunctional structure particularly for door trim grip handle of vehicle comprising a locator on said base, grip handle, cover, grip handle of which is provided with a snap for securing the cover to said base, grip handle. It is associated with the following advantageous features: - Mi...

The present subject matter relates a multilayered sealing structure (8) for the fuel filler housing (4) to block entry of fuel fumes or water vapors from the fuel filler housing to cabin area of vehicle. The sealing structure includes a circular fuel inlet pipe (6) and a multilayered sealing structure (8). The mu...

The present subject matter relates to a parking assistance system (200) for detecting and displaying text based warning information about malfunctioning of a plurality of sensors (201, 202, 203, 204). The parking assistance system (200) includes the plurality of sensors (201, 202, 203, 204), a park assist controller...

"A novel lower cross member assembly of vehicle to support radiator/intercooler". The present invention relates to a novel lower cross member assembly of vehicle to support radiator/intercooler comprising an upper radiator support member connected to a lower support member wherein said upper radiator support me...

This invention relates "to a compact cable adjuster assembly for transmission cables (MT cables) of vehicle comprising an eye end rod integrated with multiple threads on outer surface at one end which engages with corresponding threads on internal surface of eye end adjuster at one end. It is associated with th...

The subject matter disclosed herein relates to a collapsible bracket (800, 1102, 1502) for reducing pedestrian leg injuries during impact of the pedestrian leg with front side of the vehicle, in particularly to towing hook (1106) of the vehicle. The collapsible bracket (800, 1102, 1502) is positioned in between the ...

This invention relates to a reinforcement for improved lateral stiffness of front strut of vehicle comprising a longitudinal member integrally provided with a bead, which is located in proximity to front strut of vehicle to improve lateral stiffness. It is associated with the following advantageous features - Reduc...

This invention relates to No coil spring -MacPherson strut type suspension system of vehicle comprising a damper, piston rod of which is mounted with a longer jounce bumper. It is associated with the following advantageous features:- - Less number of parts. - Lighter in weight. - Cost effective. - Reduction i...

This invention relates to a cap for suspension strut rod of vehicle comprising a hollow cylindrical member with bottom side open, wherein an extended member is provided with top surface of said cylindrical member. The inner side surface of the cylindrical member is having a plurality of lugs for tight fitment of...

The present invention relates a clip mounting structure (400) for mounting any component, specifically, vehicle center console on vehicle floor penal. The present clip mounting structure (400) has a rectangular hollow structure base (401). The rectangular hollow structure (401) has a pair of head projections extendi...

The present invention relates to a rear spoiler (300) which has a plurality of rib 5 structure (302) across the lower inner edge of the rear spoiler (300) to create relation between the spoiler (300) and the glass (304) of the rear gate. Further, each rib structure from the plurality of the rib structure (302) is un...

This invention relates an improved rear floor area comprising of a single integrated reinforcement for CNG tank frame mounting, in which all the CNG tank frame mountings on one side of the vehicle i.e. RH or LH are mounted through the single integrated reinforcements.

This invention relates to a member front lower assembly used in the front under body of the vehicle comprising of a member front lower mounted with the longitudinal members with the help of rear mounting bracket and to the cross member by means of front mounting bracket wherein member front lower support is joined w...

The present invention relates to a harmonic damper for booming noise reduction in a vehicle comprises a longitudinal member connected to a bracket at one end thereof, other end of which is mounted on body panel of vehicle to allow vibration of the longitudinal member locally in dynamic condition of vehicle whic...

The present invention relates to back door assembly of vehicle for damping vibrations. The back door assembly comprises an anti-vibration sheet which is disposed between back door g!ass and back door outer panel from outer side for damping vibratious in vehicle. The present back door assembly provides an opening...

The present invention relates to a system for adjustment of rack and pinion type steering gear box comprising suspension frame sub assembly mounted with steering gear box having a rack damper screw with a stepped configuration and an octagon nut, which are adjusted by means of respective tool. Further this inv...

The present. invention relates to a system for semi-automatic manual clutch operation in automobile comprises a gear lever knob, accelerator pedal and brake pedal, each provided with a switch for engagement and disengagement of the clutch in static and dynamic condition of vehicle, wherein the SAMCO is auto conv...

This invention relates to an improved handle in automotive door of vehicle to open back door from inside comprising of inside handle integrated with outside handle wherein said inside handle comprising of a push button along with lever

This invention relates to a novel fuel injector for improvement in dynamic response of vehicle mounted on intake manifold of engine, wherein the injector comprising an elongated fuel outlet for injection of fuel, tip of which is provided with a plurality of perforations thereinside. It is associated with the followi...

This invention relates to an assembly for holding battery, coolant bottle and battery harness in a vehicle comprising a tray for battery connected with an integrated assembly of brackets for battery harness and coolant bottle. It is associated with the following advantageous features, Handling of less number of part...

This invention relates to an apron side member for improving vehicle frontal impact performance comprising atleast two sections, in which section with more stiffness adjacent to dash is connected to section with less stiffness adjacent to brace supporting head lamp. It is associated with the following advantageous f...

This invention relates to a floor mat of vehicle comprising a sheet stitched with a Velcro, which is welded to a mat at its back surface. It is associated with the following advantageous features-Prevents movement of mat on floor of vehicle.Retains aestheticness of mat, Avoids mat fouling with accelerator pedal and ...

This invention relates to a novel B-pillar of vehicle with variable stiffness to improve side impact comprising a shorter inner panel and inner reinforcement and novel door hinge reinforcement spot welded to each other. It is associated with the following advantageous features:- - To improve side crash performance ...

This invention relates to a duel fuel (CNG/LPG) passenger vehicles comprising of smaller capacity fuel tank enabling the vehicle to get started in gasoline mode followed by switching over to CNG/LPG mode.

This invention relates to a cool storage box with AC vent duct assembly of a vehicle comprising of a storage box integrated with a vent duct that said vent duct and storage box having a common opening space provided with a plurality of door shutters. it is associated with the following advantageous features:- •...

This invention relates toan assembly of front bumper beam and reinforcement in a vehicle for improved resistance to impact force comprises front bumper beam in connection with a laterally extended reinforcement having corrugated profile with variable cross-section. It is associated with the following advantageou...

ABSTRACT "Novel arrangement of oxygen sensor in exhaust system of automobile". This invention relates to novel arrangement of oxygen sensor in exhaust system of automobile comprising of an oxygen sensor connected to a pipe from exhaust at one end after flexible joint and an engine harness coupler at the other en...

This invention relates to a fuel box for dual fuel vehicles comprising of a fuel box comprising of LPG/CNG receptacle and a micro switch with the provision of CNG/LPG and petrol filling wherein the fuel box is provided with a new shape.

This invention relates to an improved gas-air mixer for dual fuel vehicles comprising of a body inserted with a pipe integrated in one piece constituting single injection moulded part as shown in fig. 1.

This invention relates to an improved assembly of gas-air mixer to air inlet pipe for dual fuel vehicles comprising of welding of the gas-air mixer and suction pipe.

"A wave type roof cross member for booming noise reduction in automobile". This invention relates to a wave type roof cross member for booming noise reduction in automobile comprising a single wave structure placed under the roof panel in width direction of vehicle, wherein crest and trough of the. cross member are...

This invention relates to an improved synchronizer pack of synchronizer comprising a synchronizer hub fitted with synchronizer rings accommodated inside a sleeve, wherein the synchronizer ring is integrally provided with a plurality of lugs on its boss area for protection against damage due to engine torsional v...

This invention relates to an air intake system for a vehicle comprising an air "filter,. which is connected to an air intake snorkel by means of air intake hose and connected to enginelintake manifold through air outlet hose, wherein the snorkel with sloping surface is provided with a water damper and water barrie...

This invention relates to a cooling structure for a cylinder block of engine to improve engine knock mitigation characteristics comprising a drill hole in a critical inter bore region of the cylinder block to improve cooling thereof. It is associated with the following advantageous features:- - More proximity t...

This invention relates to retro-fittable automobile exterior lighting syslerri mounting bracket for front fog lamp comprising a base part integrated t.o boss kind of structure for fog lamp mounting constituting a single structure, which is secured to front bumper of vehicle.It is associated with the following adva...

This invention relates to a hot casting unloading system comprising of transfer mechanism and robotic arm wherein the mechanism comprising of LM rail mounted on machined frame in which LM rail is mounted with a plurality of said LM guides to transfer the entire system linearly through a rack and pinion arrangement. ...

"Side sill reinforcing structure in vehicle for prevention of deformation m B-pillar area under side impact" This invention relates to side sill reinforcing structure in vehicle for prevention of deformation in B-pillar area under side impact comprising a, reinforcement interposed between pair of side 3ill inner an...

This invention relates to an improved pedestrian protection absorber integrated with air dam for vehicle comprising of air dam integrated to pedestrian absorber, wherein said air dam comprising of a walled structure having a base wall provided between front wall and back wall open towards top face of the absorbe...

This invention relates to snorkel for improving vehicle performance comprising a single elongated structure, inlet of which includes a substantially flat part integral to a curved part forming a curved structure involving multiple turning points for intake air flow. It is associated with the following advantageous...

This invention relates to a catalyst system used in automobiles comprising of atleast two catalysts, each of 600 cpsi cell density working in tandem.

This invention relates to an improved cooling system for automobiles comprising of an adapter to mount water pipe with o-ring to absorb thermal and engine vibration loads.

The present subject matter relates to a water jacket structure for cooling cylinder head of multi-cylinder engine. The present water jacket structure (200) has a plurality of cylindrical deflectors. Each deflector from the plurality of deflectors (202) is provided between two adjacent combustion chambers of the mult...

The present subject matter relates to a breather system (500) is provided in the engine for reducing oil content in blow-by gas and mixing the blow-by gas properly/homogcnously with fresh fillt!red air in air cleaner unit. The breather system (500) has a breather hose (506) which connects the air cleaner unit (504)w...

This invention relates to an insert bolt for blow molded part comprising a head integrated to a stud wherein said head includes a nut integrated with a plurality of flanges therearound so as to establish maximum surface contact with mating surface of adjacent blow molded part. It is associated with the following ad...

This invention relates to an novel air dam with bumper for a vehicle comprising of novel air dam connected to bumper, wherein a plurality of notch sections vertically constituting said air dam. The air dam is detachably/integrally connected to the bumper. It is associated with the following advantageous features...

This invention relates to drive system for isolating the loads of belt driven accessory and auxiliary members from the crankshaft of IC engines comprising of a driven member and driving member mounted on a crankshaft together with a slot, energising coil, sliding member, locking mechanism, spring, ball lock, ret...

This invention relates to an improved front hinge pillar of vehicle comprising of a novel bracket accommodated inside a longitudinal member provided in the front of vehicle. The present invention is associated with the following advantageous features:-_i) Reduction in number of parts, ii) Reduction in overall vehicl...

This invention relates to integrated gear shifter assembly comprising of a tube housing a shaft mounted with a plurality of forks, wherein the shaft is cocentric with the tube. It is associated with the following advantageous features:- 1. Less number of parts thereby making it compact. 2. Cost effective. 3. R...

This invention relates to improved male fuel filler hinge door for mounting of Fuel filler cap"s tether: anchorage comprising of a novel clip mounting with reduced thickness for mounting.of tether anchorage .The invention eliminates tether bracket, which leads to reduction in the following:- Weight of the vehicl...

This invention relates to novel CNG fuel system of vehicle to reduce amplitude of CNG pulsation comprising of a novel low pressure CNG hose provided bctwccn outlet of CNG low pressure filter in connection with pressure regulator and inlet of CNG injector rail, wherein the hose comprising a stepped down section c...

"A compact manual transmission for passenger cars" The present invention relates to a compact manual transmission for passenger cars comprising of input shaft first, gear in mesh with counter shaft in contact with reverse gear, wherein pinion is in mesh with final gear on differential, and a novel shifting s...

This invention relates to a reverse synchromesh system for shaft of vehicle comprising a reverse helical gear on input shaft with a helical gear on reverse shaft mounted with a synchronizer assembly.

This invention relates to anti-squeak cushion structure of automobile seat comprising a cushion pad embodying insert pad mounted on floor of vehicle body, wherein the insert pad constituting a rib structure which is virtually in contact with the floor of vehicle body. It is associated with the following advantageous...

This invention relates to improved joining method of side body outer panel and improved shape of side body outer panel comprising mounting of front door hinges, cowl side outer member and door wiring harness directly onto the Reinf, front door hinge, provision of resistance spot welding between side body outer p...

This invention relates to helical turbo charger comprising a rotor shaft provided with a helical shape, which is disposed between turbine housing and compressor housing. It is associated with the advantageous features of higher efficiency turbo, rising pressure ratio, rotational speed and power together with improve...

This invention relates to wheel speed sensing device for vehicle with antilock brake system comprising of a connector connected to a data acquisition system wherein said connector is electrically connected to antilock braking system of the vehicle for retrieving wheel pulse signals.

The present invention relates to an aerodynamic drag improvemient structure for a vehicle comprising a longitudinal curved structure to be mounted on front suspension frame wherein the longitudinal structure comprises a center part undergoing angular transition at each end thereof to be extended further on both side...

This invention relates to transmission assembly for reverse gear comprising a reverse gear mounted on each of the input shaft, reverse shaft and counter shaft together with a sleeve on the counter shaft wherein the idler gear is lengthened such that it remains in constant mesh with the counter shaft reverse gear...

"HID headlamp unit with safety lock for prevention of electrical/thermal hazard to user". This invention relates to HID headlamp unit with safety lock for prevention of electrical/thermal hazard to user comprising a housing with a back cover accommodating ballast system, wherein the housing with back cover is provi...

This invention relates to an improved hub index synchronizer assembly comprising of a sleeve accommodating hub on one side with detent spring attached to internal spline of the sleeve and a synchronizer ring connected to said sleeve and hub, wherein internal spline of the sleeve is disposed at an angle with the hor...

This invention relates to an anti theft system for automobile comprising electronic control unit of vehicle connected with global positioning system and wireless communication unit through a microprocessor unit. The system is associated with the advantages of no communication breakage between GSM, GPS & processin...

This invention relates to a novel muffler for reducing noise of a vehicle comprising of atleast one baffle plate provided between end plates, which is movable towards or away from the end plates by means of exhaust gases, wherein a resilient material is provided between the baffle plate and end plate to keep the ba...

THIS INVENTION RELATES TO A SYSTEM FOR HEATING GAS PRESSURE REGULATOR BY ENGINE CXHAUST GAS COMPRISING OF A GAS STORAGE TANK SUPPLYING HIGH PRESSURE GAS TO PRESSURE REGULATOR, WHICH IS CONNECTED TO A FILTER FOR SUPPLYING LOW PRESSURE GAS TO ENGINE THROUGH A FUEL RAIL MOUNTED ON INTAKE MANIFOLD, WHEREIN THE ENGINE...

This invention relates to novel rear bumper of vehicle for serving the purpose of mud flap comprising of rear bumper integrated with mud flap of vehicle, which is connected to rear fender lining provided in proximity to the rear tire. It is associated with the following advantageous features:- - Decrease in no. ...

This invention relates to central mounting system of engine comprising mounting of engine at its center of gravity for transmission of load therethrough, which is provided on a frame. It is associated with the advantageous features of Easy assembly, Easy to tune all torque stoppers, Easy to adopt same engine in ...

This invention relates to singly structured hood hinge and fender mounting bracket for automobiles to reduce high HIC value having substantially reverse Z-section, extended flange of which is mounted with fender and hood hinge arm. It gives rise the following advantageous features:- -Increase in energy absorption to...

This invention relates to an aero member of vehicle for improvement in drag and aestheticness comprising of a longitudinal member according to the front bumper profile of the vehicle having shorter length and height with more width. The length and height is shorter than air dam and is used in the vehicle where a...

This invention relates to an equipment for automatic application of grease in a torsion beam comprising of a grease holder with a switch for spraying grease on the beam for a fixed duration of time by means of a pneumatic cylinder. With the help of the present invention optimum grease consumption is achieved. ...

This invention relates to novel clutch cover assembly of a Diaphragm Spring Clutch for reducing the clutch pedal effort comprising a helical compression spring provided between clutch cover and pressure plate, wherein said spring clongates so as to provide force against the clamp load and release load. Thc cluch pe...

"An improved spare tire screw of vehicle". This invention relates to an improved spare tire screw of vehicle comprising of a coupler connected to spare tire screw, wherein the coupler is provided at the opening end of said screw. The invention is associated with the following advantages: - 1. Ensures proper Tig...

This invention relates to novel CNG fuel system of vehicle comprising of CNG pressure gauge directly mounted on regulator, which is connected with CNG fuel tank by means of a high pressure pipe. It is associated with the following advantageous features: - - CNG high pressure pipes are removed from circuit hence ...

This invention relates to expansion hose for reduction in the pump pressure and volume fluctuation comprising of outer hose accommodating inner hose provided with an expansion slot at one end and a throttle at other end with a helical spring. The invention is associated with the following advantageous features :...

This invention relates to a progressive throttle cam comprising novel profile of C-bracket having oval shape, which varies the pedal travel non-linearly with respect to throttle. It is associated with the following advantageous features: -   - Robust with no impact on the engine operation.   - With the same pe...

This invention relates to a test jig for determining center of gravity of vehicle seat comprising of a pivot mounted with a frame having provision for mounting of vehicle seat on one side, on the other side of which a dead weight is provided for balancing weight of the seat. This invention also relates to a metho...

This invention relates to improved side sill and side body outer for weight reduction of vehicle comprising of strength side sill and side body outer connected to each other by a resistance spot welding and side sill inner and the strength side sill are welded to each other, wherein shape of side body outer and s...

This invention relates to an improved ring gasket less prone to falling and for ease of assembly comprising a ring gasket integrated to a strip, placed between joint of two pipe flange assembly, wherein said strip is curved in shape to exert spring back pressure on pipe surface during assembly. It is associated...

This invention relates to a strengthening assembly of blow molded part comprises an assembly of thin blow molded part with a hose by means of an intermediate injection molded part. It is associated with the following advantageous features: Prevention of crushing of blow molded part by stiffening the same. Sturd...

This invention relates to B-pillar upper trim of vehicle for control of head lining/roof lining fitment, upper part of which comprising of a panel mounting with a locator on each side thereof. It is associated with the following advantageous features:- - High contact span between headlining and B-pillar upper trim...

This invention relates to a head rest frame of seat in a vehicle comprises two legs, one of which is provided with two notches maintaining a gap therebetween, wherein a slot is placed between said notches to avoid rubbing noise during adjustment for locating the head rest at desired notch by means of a guide. ...

This invention relates to a bushing of stabilizer bar with variable bi-directional stiffness for front suspension system in automobile comprising a singly structured cylindrical piece provided with a plurality of inserts therewithin, wherein each of the inserts begins from one end of the bushing to be extended in ax...

The subject matter disclosed herein relates to a suspension strut top mount assembly (300) for a wheel suspension of vehicle. The suspension strut top mount assembly (300) has support comp integrated with upper spring seat (301), bearing (303), dust cover (302), and coil spring (304). Outer sleeve of the support com...

This invention relates to an improved automobile fuel system for elimination of vapor lock comprising of a return bypass circuit in the fuel pump, which allows circulation of fuel in LPG mode and a non return valve for the recirculation.

The present invention relates to a mounting arrangement for an exhaust system of a vehicle comprising an engine mount devised to accommodate isolator of the exhaust system by combining said isolator with the engine mount. It is associated with the following advantageous features: - - Compact exhaust system moun...

The present invention relates to a system to detect instance of intermittent electrical power supply loss/reset/disability in particular ECU (s) of vehicle comprising a plurality of ECUs of vehicle in communication with a master ECU (ECU reporting the error) through a communication line wherein each of the ECUs ...

The present invention relates to accelerator pedal reinforcement of a vehicle comprising a single structure, three sides of which are spot welded to underlying dash panel and fourth side maintains a gap from the dash panel with a plurality of bracket mounting locations on the reinforcement wherein a connecting ...

This invention relates to a structure for roof rail mounting in a vehicle comprising a bracket connected to side body inner surface, which is secured to another bracket with stud resting against inner surface of roof panel, wherein the stud is orthogonal to said another bracket. It is associated with the following ...

This invention relates to a collapsible hood reinforcement of vehicle which is ·,vvclded to underlying striker reinforcement and placed between hood outer panel and inner· panel, wherein the hood reinforcement comprises a single structure, one side surface of which is provided with a plurality of slots and a notch ...

This invention relates to a refuelling interlock device in CNG/Dual fuel vehicle comprising of a refuelling interlocking device positioned in fuel box that, the interlocking device is actuated by a means in compressed condition so as to complete the vehicle ignition system causing starting of vehicle. ...

This invention relates to an improved front bumper and head lamp assembly of vehicle for accommodating air dam comprising of surfaces in head  lamp  housing  and  in  front  bumper  inner  surface  for accommodating air dam.

The present invention relates to an air dam integrated with front bumper of vehicle to improve aerodynamic performance of vehicle comprising an aerodynamic elongated member constituting air dam integrated to lower area of the front bumper wherein root of air dam is thicker in the longitudinal direction thereof....

This invention relates to an electronic parking brake system comprising a novel actuator assembly, which processes various input variables for optimum braking force to be applied on the rear wheels of vehicle to prevent locking thereof in dynamic condition and maintain stability of vehicle. It is associated wit...

This invention relates to a gear shift lever assembly comprising lever rod with axle lever connected to shift pin at one end together with a pivot ball at the joint of the lever rod and axle lever wherein a threaded joint is provided at the interface of socket and housing for assembling thereof. Further this inv...

The present invention relates to a fastener in a part of vehicle comprising a longitudinal member constituting a cantilever snap extended at one end in transverse direction, which is further extended in longitudinal direction of the snap maintaining a gap therebetween. It is associated with the following advant...

The present invention relates to cross rib structure to eliminate sink mark from the mounting part comprising a plurality of junctions of atleast two ribs constituting multiple offset ribs. It is associated with the following advantageous features:- - Low accumulation of material in the local area i.e. around t...

This invention relates to engine mount and bracket assembly for mounting engine in a vehicle, wherein the engine mount comprising a bracket for connection with chassis and an isolator bush, side surface of which is provided with a novel side stopper, which is assembled to a novel engine mount bracket. It is ass...

This invention relates to an improved head lamp and front bumper assembly of a vehicle to improve fit and finish comprising of a head lamp with a rib structure and front bumper also provided with a rib structure maintaining a gap therebetween within the tolerance limit.

This invention relates to a caseless compact transmission differential for a vehicle comprising a final gear held by means of a cross shaft, which is mounted with a speedometer gear. It is associated with the following advantageous features: - Compact in size - Light weight - Cost effective - Improved performan...

This invention relates to a novel inline cam in dies comprising of driver mounted on upper die and slider slides on lower die recess, wherein driving surfaces are placed in line with the slider cam body and cam slider guide rail and positive return are mounted on the slider.

This invention relates to a mounting structure for roof rail of vehicle comprising a stud secured to welded vehicle body including side body panel, atleast one inner panel and roof panel wherein the roof rail is mounted through the stud. it is associated with the following advantageous features: - Compact - Xas...

This invention relates to a manual transmission shaft less shift system to shift gears in automobile comprising a frame forming a single structure including a plurality of forks, each of which is integrated to respective yoke and lug, which is accommodated in a transmission case. It involves the following advanta...

This invention relates to a worm clamp with adjustable internal diameter comprising a clamp body constituting a loop of sheet metal, end of which is secured to a tightening/releasing module including a housing accommodating a screw, torquing of which varies internal diameter of the clamp, wherein the clamp body is p...

This invention relates to a strengthened molded part by strengthening joinery between two materials of the molded part comprising of a hard material part embedded into soft material part, wherein the hard material part is provided with atleast one hole adjacent to joinery of said parts which acts as mechanical lock....

This invention relates to a sealing structure for plastic fuel filler assembly of vehicle comprising a single piece forming substantially a ring structure, which is accommodated in the housing of said fuel filler assembly wherein outer profile of the ring structure corresponds to the inner profile of base of housing...

This invention relates to an injector coupler tool for ergonomic assembly of electric couplers of fuel injector comprises a handle connected to a curved member including a plurality of arms. end of which is provided with a coupling means to couple with said electric coupler. It is associated with the following advan...

This invention relates to a stopper for prevention of pipe rotation in motor vehicle comprising a bracket, one member of which is fixedly secured to fuel pipe and another member is in engagement with a resin clamp. it is associated with the following advantageous features: Prevention of fuel pipe rotation in r...

This invention relates to a door lock canceller malfunction indicator system comprises KLE controller connected tn sir bag controller, Ignition switch, door lock/unlock bu.ttons wherein the KLE controller is provided to detect any malfunction in electrical connection between the air bag controller and KLE contr...

This invention relates to a system to capture operator efficiency on a station of power and free conveyor comprising of RFID tag, data in which is read by RFID reader which is connected to a graphic operator terminal provided in connection with a computer through PLC.

This invention relates to an external system for conditioning multiple vehicular engines" temperature comprising first heat exchanger in flow communication with a cool storage through second heat exchanger, wherein said second heat exchanger and third heat exchanger(cool storage), each of which is connected to r...

This invention relates to an improved U-lug for improved part fitment in motor vehicle comprising of a U-lug, one leg of which is. integrated to a member having substantially L-section at the end thereof, wherein locking surface of the member accommodates body panel of vehicle. Further according to this inventio...

This invention relates to an anti-loosing with effective locking U-bolt and nut assembly for motor vehicle comprising aU-bolt, each leg of which is integrated to a variable diameter threaded part at the end thereof, which includes larger diameter part with threads in a direction opposite to that of smaller diamet...

ABSTRACT "An improved CNG cylinder valve" This invention relates to an improved CNG cylinder valve comprising of CNG cylinder valve with only one side opening and other side is having inbuilt plug.

This invention relates to fender protector with improved stiffness for a vehicle comprising a single sandwiched structure with a plurality of strengthening ribs and mounting points. It is associated with the following advantageous features: Maintains appearance by avoiding distortion of visible layer. Facilitate...

This invention relates to a pedestrian protection hood for improved energy absorption during pedestrian head impact comprising a hood outer panel joined with a hood inner panel being hemmed at one end and sealed at other end; wherein the inner panel constitutes a cup structure including a base between two side w...

The present invention relates to a system for improved cooling of cylinder block of engine in a motor vehicle comprising of novel water jacket in the cylinder block of engine wherein said jacket is provided with coolant deflector so as to direct the coolant towards top dead center of the block. It is associated ...

The present invention relates to an air cooling system for underhood components of vehicle comprising of a cooling duct connected to front grille of bumper to direct ram air flow to specified location of catalytic converter. It is associated with the following advantageous features: - Cooling down the catalytic...

This invention relates to an electrical nut runner comprising of a pop-up with conveyor mounted with a pallet constituting bottom portion and a power head constituting top portion, wherein said top and bottom portion are operated by electric motor. Said nut runner of the proposed application prevents transmissio...

This invention relates to a bracket assembly of trunk lid in automobile to prevent noise during operation thereof comprising a metallic hinged bracket assembled with non metallic auxiliary bracket wherein the auxiliary bracket is integrated to a plurality of sleeves, ,which is interposed between the hinged brack...

This invention relates to a gear shifter assembly with variable lever ratio for a vehicle comprising a gear knob having a centrally placed tubular section with a lug to be engaged in a guide of lever rod so .as to set lever ratio according to requirement. It is associated with, the following advantageous feature...

This invention relates to an improved front fender of vehicle comprising a sheet above fender mounting surface connecting two intermediate points of the fender surface. It is associated with the following advantageous features: - Maintenance of visible surface as per the styling intent. - Improvement in stiffne...

The invention relates to a method in a diagnostic system for detecting and displaying the cause of engine-restart failure in a alternative fuels compliant vehicle during an intermediate stoppage mode of the vehicle, the system comprising a vehicle engine activable by operating an ignition switch,a starting motor p...

The invention relates to a self-diagnostic system to provide indication and protection for refuelling of alternative fuels driven vehicle, the system comprising an electronic control unit incorporated with a logic rule; a fuel lid having a fuel-lid sWitch; a plurality of engine operation sensor; a CNGfuel level/p...

The invention relates to a system for detection and communication of faults in fuel injection device of alternative fuel compliant vehicles, comprising an engine rotatable by a starter motor and to generate an initial running speed 0 the engine; an engine rotatable by a starter motor and to generate an initial runni...

The present subject matter relates to a plastic bracket structure (300) for holding ABS sensor hose and brake hose in strut assembly of a vehicle. The plastic bracket structure (300) has a cylindrical structure (301) which inserts in strut damper outer tube. The plastic bracket structure (300) has an integrated brac...

The present invention relates to an insert assembly for fixing insert over alloy wheel of vehicle comprising a pair of insert members connected by means of a locator at one end and a connector at other end constituting a single structure. It is associated with the following advantageous features:- Avoids high s...

The present invention relates to a reinforcement cross member of vehicle comprising a single structure forming substantially a channel with a through hole, which is provided with a plurality of embossed parts together with slots. It is associated with the following advantageous features: - Avoids air lock durin...

The subject matter disclosed herein relates to an energy absorber which is positioned in between the front bumper and lower beam of the vehicle. The energy absorber (300, 600) is mounted on the lower front longitudinal beam (700b) where lower part of radiator is mounted. The energy absorber (300, 600) is made of sin...

This invention relates to louver with garnish for air conditioning unit of vehicle comprising of atleast two louvers accommodated inside a louver housing integrally provided with a separator therebetween, wherein the louvers are detachably attached to said separator and said housing is provided with a special ou...

This invention relates to an improved tooling for bearing cap face and crank half bore milling comprising of a novel bearing cap face milling cutter accommodating a novel crank bore half round milling cutter.

This invention relates to an improved garnish for maintaining designed gap between quarter glass and body panel of vehicle comprising a longitudinal member including a supporting member mounted with a dividing member having clip mounting to obtain two parts, wherein one part, end of which is integrated to a flan...

The present subject matter discloses a torque rod assembly (400) for mounting engine body on vehicle body to remove initial stress generated in torque rod bracket during assembly. The torque rod assembly (400) has a torque rod (400a) with U shaped bracket (406) at one end and big bush at other end. Both the U shaped...

This invention relates to an improved fuel delivery pipe for fuel injection system of vehicle comprising of a fuel delivery pipe integrally provided with atleast four legs for mounting on intake manifold and anti rotation member to control rotation of injector supporting the rail, wherein the injector is mounted ...

The present invention relates to reinforcement of split type parcel tray in automobile comprising a longitudinal member integrated to a protruded part with a hook for engagement of openable board string therewith. It is associated with the following advantageous features:- Integration of child part to parcel tra...

The present invention relates to body side engine mount system of vehicle comprising an engine mount bracket between auxiliary support bracket, and side support bracket on both sides of the vehicle, wherein said brackets are held by means of sub member on engine side and secured to the long member on body side o...

The present subject matter relates to a load adjustable parallel proportioning valve in dual braking system in vehicle. The present load adjustable parallel proportioning valve has a spring receiving plate (304) which is integrated with a magnetic coil (304a). Further, the magnetic coil (304a) integrated spring rece...

This invention relates to a reinforcement to prevent stress concentration on resin part of vehicle comprising atleast one single structural piece placed on the resin part of vehicle at/near mounting area thereof, outer profile of which follows the outer profile of adjacent parts thereto. It gives rise the followi...

This invention relates to a novel coolant bottle for automobiles comprising of a depression below its extended curved neck constituting obstruction for preventing spillage of coolant from said bottle during movement of vehicle. The present invention efficiently prevents leakage of coolant from the bottle particu...

This invention relates to a single structure rail assembly for bi-fuel vehicle comprising of a CNG rail and gasoline rail connected to each other together with a plurality of extended members provided with said CNG and gasoline rail for mounting on intake manifold, wherein said rail assembly is mounted at atleas...

The subject matter disclosed herein relates to a roof front header which is positioned below roof panel and windshield. The present roof front header is made from plastic material. The present roof front header is of two types 1) bolted type plastic roof front header (403) and 2) molded type plastic roof front heade...

The present subject matter relates to A driveshaft boot guard (200) for protecting boot cover of constant velocity (CV) joint of driveshaft from stone, mud, and rock. The driveshaft boot guard (200) includes a semi cylindrical body (202) to cover complete lower, front and back side of boot cover (502) of the CV join...

The present subject matter relates to a rear wheel fender cladding structure (400) for reducing the aerodynamic drag coefficient at rear of vehicle. The rear wheel fender cladding has an extended and inclined portion (404). This extended and inclined portion of the rear wheel fender cladding allows delayed separatio...

The present invention relates to steering gear box stopper for gear box stroke control in automobile comprising a rack bar supported by means of a housing, wherein each end of the rack bar is threadingly locked with a nut in conjunction with a drag rod to establish connectivity with one of the front wheels. It ...

The present subject matter disclose a single end pivoted rocker arm assembly (300) for actuating double valve using single cam shaft lobe (602) and adjusting valve lash independently in internal combustion engine. In the present single end pivoted rocker arm assembly (300) two arms are integrated with each other to ...

This invention relates to novel adhesive type balance weight for alloy wheel of vehicle comprising of a plurality of buttons connected to each other by means of a bridge wherein side surface of each button is tapered, which together form recession slot between the buttons provided on a double sided tape for pasti...

The present subject matter relates to adjustable hanger bracket structure (200) for mounting exhaust pipe system on the underside body of vehicle. The present adjustable hanger bracket structure includes a first structure member (202) and a second structure member (204). The first structure member (202) is connected...

This invention relates to an improved tailored welded blanks in a vehicle to improve yield comprising of a thinner blank welded to a thicker blank provided in the front door wherein said thicker blank is tapered.

The present invention relates to outlet comp ventilator in open section of the vehicle comprising a ventilator and a seal between inner and outer cover, wherein the ventilator is provided with a plurality of extended lugs for ease of assembly with said inner.cover. It is associated with the following advantageou...

"Ari i::iproved grille of vehicle for reducing visibility of harness and inner par:::! and balancing underhood thermal gradient". "i"kiis invention relates to an improved grille of vehiclc for reducing visibility of sp , > r n r x t . and inncr panel and balancing undcr"noofi thermal gradicnt ccjnlprising of a s...

ABSTRACT "Novel underbody structure of vehicle to resist vehicle cabin deformation in head on collision". This invention relates novel underbody structure of vehicle to resist vehicle cabin deformation in head on collision comprising of a floor between front and rear wheels provided with atleast two longitudina...

ABSTRACT novel rear axle twist beam of vehicle to improve lubrication by using oil and a method of manufacturing thereof". This invention relates to a novel rear axle twist beam of vehicle to improve lubrication by using oil comprising of a centre beam connected to at least one trailing arm at the end, in which...

This invention relates to an aerodynamic structure in rear under floor of vehicle comprising of an air dam in front of fuel tank and another air dam in front of muffler wherein the air dam constituting a longitudinal member to reduce drag and improve cooling performance. It is associated with the following advantag...

This invention relates to an automatic multi-level parking system comprising of a plurality of compartments for accommodating vehicles, which are retrieved and deposited by means of a docking system comprising of an intermediate transfer system mounted with a docking unit, in which the docking unit is provided with ...

This invention relates to an improved brace hood lock comprising of a bead of shape for example circular on a panel around weld nut to reduce stress.

This invention relates to an assembly for accommodating spare tire in luggage compartment of hatch back passenger vehicle with duel fuel option using toroidal gas tank comprising of a spare tire in vertical/ inclined position above toroidal tank wherein the spare tire is mounted on a specially designed bracket such ...

This invention relates to an improved mounting of radiator condenser unit comprising of a radiator condenser unit with a rubber mount, which is fitted in bracket radiator and a transverse member having a provision for mounting.

This invention relates to an improved hood hinge arrangement for passenger car hood comprising of arm, bracket and pivot wherein arm is provided for the mounting of hood, said bracket is mounted on the cowl box system and the pivot is provided for the rotation of arm of hinge on bracket.

This invention relates to a mounting for front seat belt retractor comprising of an improved panel center pillar inner wherein distance from the seat belt retractor is atleast 15mm without a hole and a flat area in said panel is provided for mounting ELR.

This invention relates to a vehicle with improved quality front and rear bumper comprising of a bracket connected to front area of vehicle, other end of which is mounted with fender, and other bracket connected to weld body at one end, bumper end of which is mounted with rear bumper.

This invention relates to a novel welding sequence to form front under body structure of vehicle comprising of :- Preparation of the front cross member (Item -A), longitudinal members (Item -B), Cowl Box (Item -C) 8B Dash comp (Item -D) as sub-comp in different welding jigs, Preparation of a plurality of sub-assembl...

This invention relates to an improved method for using plastic trim to assist serviceability and quality comprising the following steps of:-Removal of the required shape from the plastic trim, Assembling additional molding to cover the cutting shape on the plastic trim.

This invention relates to an improved front seat back for creating scoop in automotive seating to increase leg room and enhance aesthetics comprising of a seat back frame in contact with PU Pad in the front integrated with wires for clamping wherein the seat is covered by means of a trim including scoop area, genera...

This invention relates to an improved joint for steel and copper LPG pipe connection in LPG vehicles.

This invention relates to an improved door.

A device for holding a fire extinguisher placed between driver and co-driver seat in cargo and passenger cars consists of a clamp type bracket (2) for holding the fire extinguisher (1), a support bracket (3) for resting the front neck of the said fire extinguisher. The said clamp type bracket (2) is assembled to the...

This invention relates to an improved rear under body of monocoque structure for mounting CNG cylinder comprising of a plurality of reinforcements inside longitudinal members of the rear under body.

This invention relates to an integrated roof lining holder in interior plastic trims for passenger car comprising of atmost two sliders and a plurality of ribs.

This invention relates to a seat for special automotive applications for enhancing the ease and utility of occupants comprising of a seat provided on upper frame attached to a foldable leg wherein a bracket is mounted at both ends of the seat.

This invention relates to an improved Sunvisor in four wheelers comprising of a perforation in the card board of Sunvisor constituting weak zone.

This invention relates to a cam shaft thrust plate integrated with lubrication circuit to avoid oil splashing in cam-sensor area of a gasoline engine comprising of a thrust plate fitted on cylinder head and face, rotor sensing provided on cam-shaft for position detection, a gasket mounted on the cylinder head and fa...

This invention relates to front timing belt cover with integrated clamp mounting comprising of a mounting for clamp integrally provided with engine cover to mount coolant hoses and wire harnesses.

This invention relates to Pseudo-Synchronized Reverse Gear Shift system comprising input shaft extending downward to be in constant mesh with idler for avoiding blockage, in which output shaft is positioned adjacent to the input shaft.

This invention relates to a hair mopper for adsorbing oily liquids comprising of a perforated cloth stuffed with hair.

This invention relates to an automatic system for vehicle variants check comprising of a computer installed with master data for different models of vehicles provided in connection with vehicle tracking system with a display. The system of the instant invention prevents installation of wrong parts in vehicle and ens...

This invention relates to a novel front seat mounting bracket comprising of a flange for welding of seat mounting bracket with the side sill, which extends from top of the side sill in downward direction and a flange in the seat mounting bracket with floor for welding.

This invention relates to a spring seat for torsion beam type of rear suspension of vehicle comprising a upper side having a stopper on its outer peripheral spring resting surface and lower side having outer peripheral top surface mounted with a lug and a lip with an annular space therebetween wherein an improve...

This invention relates to aerodynamic drag reducing structure for rear bumper of a vehicle which comprises a bumper extenoion assembly having a bumper extension member with grill wherein a duct is interface fitted to the grill on one side and to the rear bumper/extension member on other side. It is associated w...

"A novel cooling fan for engine of automobile" This invention relates to a novel cooling fan for engine of automobile comprising of a shroud mounted with fan for engine, wherein a shroud extension is integrally provided with rim of fan mounting. The invention does not require mud flap unlike prior art. ...

This invention relates to improved rear bumper of vehicle comprising of bumper integrally provided with dog house (mounting part) for mounting on rear panel of vehicle .wherein a novel dog house is provided to reduce area of contact with the rear panel. The present invention results in prevention of rust in body pan...

A reusable, pressure sensitive adhesive surface with non-uniform, hierarchical nanopillar structures and a method of preparing the same by morphological self-organization and crosslinking of a porous hydrogel template, controlling the 5 amount of water removed from the gel layer and further by moulding the templa...

The present invention relates to an integrated mounting for rear seat backrest and Isofix anchorage of a vehicle comprising of bracket to mount rear seat backrest integrated to isofix anchorage mounting on each side.

The present invention relates to back door of vehicle for tilted packaging of spare wheel comprising of back door outer panel connected to inner panel with reinforcement there between, whereiri outer panel mounting surface for spare tire is provided at an inclination for tilted mounting of said spare tire. It i...

This invention relates to a novel seat in a passenger car comprising of a seat provided with guide thereunder, along which back rest with head rest moves, wherein profile of said back rest and head rest is same both in the front and back and profile of the seat is provided with a uniform curve. The invention is ...

This invention relates to a protector mounting for vehicle fuel filler hose comprises a bracket secured to a wire clamp for connecting with the protector. It is associated with the following advantageous features: Elimination of bracket and snap. Reduction in weight and cost. Improvement in fuel efficiency. Impr...

This invention relates to a system of deformable hood switch and hood lock member in a vehicle for reduction in head injury criteria comprising a hood switch mounted on hood lock _member by means of a fastener in which the hood switch includes a bracket with an anti rotation feature accommodating a spring loaded...

This invention relates to a protector mounting for vehicle fuel filler hose which comprises a clamp integrated to one inner side surface of the protector to hold sajd hose. It is associated with the following advantageous features: l Elimination of bracket and snap. Reduction in weight and cost. Improvement in f...

The present invention describes a reverse gear mechanism in an automobile gear transmission. The reverse gear mechanism of the present invention includes a means to rotate the reverse idler gear to a predetermined angular position when the hub of the reverse idler gear is positioned on spline section for preventi...

"Air distributor duct ;assembEy of vehicle" r:~ :-,g,;,? ; r. nvcntion relates to air distributor duct assembly of vehicle comprising of ax! air distributor duct mounted on inner side of front burnper, wherein said air ..- . : i..: is having a plurality of inlets, outlet of which is directed towards specific :-:...

ABSTRACT "A novel U-nut structure to fasten mating part of vehicle". This invention relates to a novel U-nut structure to fasten mating part of vehicle comprising of a U-shaped screw nut, which comprises a lower member with a hole and a upper member with a corresponding hole together with a connecting part ther...

This invention relates to a system for functioning of micro switch of vehicle with heavy snow deposition comprises of a micro switch fitted in the hood latch, actuation (pressing/unpressing) of which gives signals to other parts of vehicle for different purposes.

This invention relates to an novel telescopic crash box of vehicle for absorbing impact energy comprising of back plate connected to a pin and outer crash box, wherein the pin loaded with resilient material supports an inner crash box mounted on bumper beam of vehicle such that the inner crash box is telescopically...

The present invention relates to an internal combustion engine with independent port structures , comprises of two intake independent valves, two intake ports, two injectors and a combustion chamber wherein the intake ports have a straight profile and are isolated with each other to increase tumble motion withou...

This invention relates to a snap comprising a vertical member integrated to horizontal member constituting a single piece, locking surface of which forms a substantially L-section, wherein one of the members is integrally provided with a protruded part at one end thereof. It is associated with the following advant...

This invention relates to a shifting system for fifth and reverse gear of vehicle comprising of atleast two shafts with one of them supporting a fork at each end for fifth and reverse gear engagement, wherein a yoke is provided with each of the shafts for shifting into fifth or reverse gear and third or fourth gear....

This invention relates to an improved parcel tray of vehicle to reduce visibility of luggage comprising of a parcel tray, slab surface of which is provided with atleast one slot to accommodate cushion comprising of a wider parcel tray, slab surface of which is provided with atleast one slot to accommodate cushion...

The. present invention relates to an improved D-pillar of vehicle to reduce torsional stresses comprising of an outer panel and inner panel joined by means of a flange wherein said outer panel is provided with a bead. It is associated with the following advantageous features:- - Reduction in weight of D-pillar ...

This invention relates to Protector mounting assembly of vehicle for fuel filler hose comprises a wire clamp connected to a protector wherein the clamp includes a coiled wire, each of two ends of which forms a hook facing a supporting means for bolt. It is associated with the following advantageous features: Elim...

This invention relates to improved partitions for four wheeler cargo vehicle comprising of outer partition frame (1) bolted to vehicle & inner partition door frame (2) welded to outer partition b/w hinges (3). wherein said hinges (3) allow door to swing 85 stoppers (8) are provided on outer partition frame (1) to st...

This invention relates to Internal by-pass circuit for air bleeding to improve the cooling performance of cylinder head comprising of a cylinder head mounted on a cylinder block wherein water from radiator enters into the cylinder block water jacket, pressurized water from which does the cooling of said cylinder hea...

The present subject matter relates to a single cable gear shift system (400) for selecting and shifting gears in manual gear transmission system of a vehicle. The single cable gear shift system (400) has a rotating knob (401) which rotates in counter clockwise and clockwise direction for actuating/pushing low gear s...

The subject matter disclosed herein relates to an exhaust system (100) for treating emissions of internal combustion engine and converting the emissions into acceptable form. The exhaust system (100) has a pressurized transfer chamber (1) provided after catalytic converter (10) in exhaust downstream direction to cap...

The subject matter disclosed herein relates to an apparatus for improving aerodynamic drag to improve fuel consumption in vehicle (201). The apparatus comprises a fluid duct (204) to directionalize flow of exterior air towards rear (209) of front wheel (208) to reduce wake area. The fluid duct (204) has a fluid inle...

The present subject matter relates to a multi shaft gear shift system (MSGSS) (500) for shifting gears in vehicle. The MSGSS (500) has a multi shaft gear shift tower (300) and a plurality of electric motors (501a, 501b, 501c) connected with pulleys (301, 302, 303) of the multi shaft gear shift tower (300) through be...

This invention relates to electronic brake pad wear indicator unit in disc brake system of vehicle wherein caliper assembly of the disc brake system includes a pair of brake pads resting against carrier and housed inside housing of caliper with a disc therebetween, in which the indicator unit comprising a sensor mou...

The invention relates to a battery mounting structure comprising (a) battery mounting bracket member(18), having U-shaped upper platform (18a) with two inverted L-shaped legs (18b), the rear end (16) of said battery mounting bracket (18) attached to a horizontal flange F3 and two vertical flanges F1 & F2 , each prov...

The present subject matter discloses a nozzle defroster assembly (100) for passage of air flow without air leakage. The nozzle defroster assembly (100) includes a first part (101) and a second part (102) that is joined with the first part (101). The first part (101) has two grooves to receive raised portions of the ...

The subject matter disclosed herein relates to a crash box structure (600) for absorbing impact energy of during vehicle collision. The crash box structure (600) has a front upper absorber member (602), a front lower absorber member (604), a rear upper absorber member (606), and a rear lower absorber member (608). T...

A split type air guide (100) includes an upper part (102) integrated with a bumper grill (104), the upper part (102) having a top surface (106), a first side surface (108) and a second side surface (110), the first side surface (108) having a ribbed edge (112), and the second side surface (110) having a zig-zag edge...

Loading of rear structure components (200) of a vehicle is disclosed. The rear structure components (200) includes a rear floor (202); a plurality of side body (204) secured to the rear floor (202), the plurality of side body (204) including a plurality of trim less quarter panels (206), each of the plurality of tri...

An integrated bumper grille (100) for a vehicle. The integrated bumper grille (100) includes an upper grille (102); a lower grille (104) integrally coupled to the upper grille (102); and a plurality of ribbed connections (106) integrally coupled to the upper grille (102) and the lower grille (104), the plurality of ...

The subject matter disclosed herein relates to an adjustable hinge assembly (600) for adjusting pop-up height trunk lid of vehicle. The adjustable hinge assembly (600) comprises a hinge link (603) having one end (603d) and another end. The other end has a plurality of U shaped receiving portions (603a, 603b, 603c) t...

A ventilator cover (312) disposed on a ventilator (310) in a luggage compartment (300) of a vehicle, the ventilator (310) positioned substantially on a rear skirt panel (306). The ventilator cover (312) including an arcuate vertical part (502) covering the ventilator (310), the arcuate vertical part (502) having a f...

The present invention relates to a fender lining structure 200 to make installation of the bumper easy in the assembly line. The fender lining structure comprises an extended flange 201 having a mounting hole 202 for mounting a bumper, a plurality of ribs 203 on bumper side of the extended flange 201, and a pluralit...

The present subject matter describes an assembly (100) for inhibiting wrong gear shift operation in AMT vehicle. The assembly (100) comprises a shift shaft (101) having a lever reverse interlock (105) and a case gear shift guide (102) having a hole to receive the shift shaft (101). The assembly (100) further include...

Described herein relates to system for indicating service due of fuel injectors of a bi-fuel (BF) vehicle. The system includes processor (201, 104) coupled to a memory (106, 203) and a service due indication module (108) to count fuel injection pulses (Pi, P2) for a plurality of gaseous fuel injectors and a pluralit...

Described herein relates to system and method for detecting gear shift intention or state of gear shift lever (104). The system (100) comprises a first switch (101), a second switch (102) and a draw wire potentiometer sensor (103) to determine state of gear shift lever. The voltage output from the draw wire potentio...

Described herein is a trim structure (302) for pillars of a vehicle. The trim structure (302) includes a protrusion (304) integrally formed on edge of an external surface of a trim flange, wherein the protrusion (304) is extending away from the external surface of the trim flange so as to lock the trim structure (30...

The subject matter disclosed herein relates to an exhaust gas heat recovery system (100) for warming up engine and engine coolant. The system (100) diverts the exhaust gas from exhaust gas pipe (9) to engine body (2) via exhaust in pipe (6). The engine body (2) has first and second heat transfer cavity (10, 11) tran...

An isofix anchorage structure (100) includes a tubular cross member (102); a plurality of isofix bars (104) defines U-shaped profile having an edge (106), and a plurality of extensions (108) coupled to the tubular cross member (102); a plurality of isofix brackets (110) defining an arcuate profile having a base (112...

The subject matter disclosed herein relates to a wrong fuel nozzle inhibitor (100) positioned at fuel filler neck to prevent insertion of wrong fuel nozzle into the fuel tank. The device (100) has cylindrical housing (101) having two spring loaded cylindrical shafts (104) coupled with two flaps. Upon insertion of fu...

The present disclosure relates to a guide structure (300) mounted behind a front bumper lower grill (102). The guide structure (300) includes an upper portion including two upper horizontal walls (306-1, 306-2) which are being blend connected to form an acute angle therebetween, the blend (306-4) connected upper hor...

An impact resistant vehicular door trim assembly (200) is disclosed. The vehicular door trim assembly (200) includes a door trim board (202) having a plurality of weld bosses (204); a bezel (206) configured to be positively mounted on the door trim board (202) through a plurality of snaps (208) being disposed across...

The present disclosure relates to a door sill guard (100) for a vehicle. The door sill guard (100) comprises a plate (102) formed with cut portions corresponding to predefined characters, a plastic insert (104) having the predefined characters embossed on its top surface, the predefined characters protrude through t...

The present disclosure provides an HVAC control unit (200) with a dial knob assembly for a manual air conditioning system of a vehicle. The HVAC control unit (200) includes a dial knob (204) having an inner fixed portion (204-1) and an outer rotary portion (204-2). The outer rotary portion (204-2) includes an engagi...

The present disclosure relates to an equalizer (200) of a parking brake lever (100). The equalizer includes an integrated gear-nut (202) screwed on a threaded portion (102-T) of a tie rod (102) passing through a recess formed on a base (106) of the equalizer (200); and a guide pin (204) mounted on an upper flange (1...

The present subject matter relates to a device holder system (600). The present system (600) includes a media system (500) having a mounting hole (502) that is covered with a cap (102) and an electronic device holder (100) configured to be mounted to the mounting hole (602). The electronic device holder (100) consis...

The present subject matter relates to a device holder system (600). The present system (600) includes a media system (500) having a mounting hole (502) that is covered with a cap (102) and an electronic device holder (100) configured to be mounted to the mounting hole (602). The electronic device holder (100) consis...

The present subject matter relates to a device holder system (600). The present system (600) includes a media system (500) having a mounting hole (502), an electronic device holder (100) configured to be mounted to the mounting hole (602) via connecting shaft (400). The connecting shaft (400) consists a connecting r...

The present subject matter relates to a connecting shaft (400) for connecting a media device to mounting hole of media system on vehicle dashboard. The connecting shaft (400) includes a connecting rod (401). The connecting rod (401) has a plurality of protrusions (402) at locking end (400a) and a spherical structure...

A SPARE TIRE HANDLING AND POSITIONING ASSEMBLY The present subject matter relates to a spare tire handling and positioning assembly 100. The assembly 100 comprises a screw wrench 101, a screw link 102, a spindle 201 fixedly connected to a lower end of the screw link 102, a spindle case 105 having a slot for the sp...

The present subject matter disclosed herein relates to a rack and pinion housing structure (800). The rack and pinion housing structure (800) includes a pinion input shaft (200), a pinion cover (300), a pinion housing (400), an oil seal (500), rubber plugs (600), and a dust cover (700). The pinion housing (400) rece...

Described herein is a method for detecting cranking issues in a starter motor (116) and warning the user and/or restricting functionality of the starter motor upon detection. The method (200) includes determining (203) whether the starter engaged flag is ON; detecting (204) inching condition of the starter motor (11...

The present disclosure relates to a traction battery pack protection system (100) including a hardware protection circuitry (200) having a first transistor (120) and a second transistor (121). In case of fault generation, the first transistor (120) act as closed switch and the second transistor (121) act as open swi...

The present disclosure relates to an oil sump assembly (100) for a vehicle's engine structure. The assembly (100) comprises a lower panel (100b) and an upper panel (100a) having a connecting face (116) to be connected on a connecting face (116) of the lower panel (100b). The upper panel (100a) comprises an oil filte...

Described herein is an Engine Control Unit (100) for reducing emissions and improving fuel economy. The ECU (100) includes a fuel controller (200) coupled with a plurality of fuel injectors (101) positioned in an air intake manifold for controlling fuel injection in split mode. The fuel controller (200) is configure...

The present disclosure relates to an HVAC system for preventing leakage of refrigerant from a compressor to the atmosphere. The HVAC system comprises the compressor (200), a storage tank (202), a pressure relief valve (204) on the compressor (200), two conduits (206 and 210), and a one-way check valve (208). The sto...

The present invention relates to a manual control system for HVAC of a vehicle comprising a temperature knob (300) connected to a thermistor. If a required temperature selected by the temperature knob (300) is from a cooling zone (300a), no heating of air occurs. A hot air damper (407) closes an opening between a fi...

MULTI PIECE PULL COLLAR ASSEMBLY FOR GEAR SHIFT LEVER A multi piece pull collar assembly (100) for a gear shift lever (102) includes a lower pull collar (104) secured to a lower portion of the gear shift lever (102), the lower pull collar (104) defining a first plurality of walls (106) having at least one male prot...

A doghouse structure on a trim part (200, 300) of a vehicle is provided. The doghouse structure comprises a top surface (201, 301) comprising two of a supported side (201a and 201b, 301a and 301b) and two of a free side (201c and 201d, 301c and 301d). Two of a support wall (202 and 203, 302 and 303) is provided on t...

The present disclosure relates to a reinforcement structure (200) provided to an inner door panel (212-1) of a vehicle which comprises a first end (202) attached at the door hinge area of the inner door panel (212-1) and a second end (204) which is wrapped around the vehicle handle area of the inner door panel (212-...

This invention relates to an improved single piece glove box for a vehicle and anovel see-saw type latch comprising of a cover over latch of the glove box so asto avoid interference of items during operation and a safety plate in the latch toavoid injury to finger during operation of the la...

This invention relates to an improved barrel type louver compnsmg of aplurality of extended parts on one surface and locating holes on either side, inwhich a profile is provided around the periphery of louver. This invention alsorelates to a method of assembling louver on instrument panel o...

This invention relates to a system for anchoring and securing fuel filler cap of a vehicle comprising of a tether with fuel filler cap with one end fixed onto the cap fuel filler and other free end to be fixed on the vehicle, and a lever of the fuel lid lock for arresting slippage tendency of the tether of t...

This invention relates to a system for mounting spare tire comprising of a retainer with floating nut for mounting spare tire in vertical position on panel in inflated and deflated position wherein the retainer with floating nut is welded on said spare tire mtg bracket.

This invention relates to integrated system of suction pipe and resonator for reduction in intake noise comprising of resonator provided between air cleaner and suction pipe, wherein the suction pipe is integrated to said resonator. The system is associated with the advantageous features as follows:-   - Longe...

This invention relates to a single point mount crash guard comprises a single structure placed between hitting mass and target body which includes a flat part integrated to an inclined part constituting absorber and deflector of the" hitting mass load during frontal crash. It is associated with the following adv...

The present subject matter relates to a water jacket structure (600) for cooling cylinder head of multi-cylinder engine. The water jacket structure is provided with a plurality of restrictors (602). The plurality of restrictors (602) is placed at end of each cylinder chamber of the water jacket structure. The plural...

The present invention relates a torque based engine management system (200) for managing torque demand of convention alternator (202) and idle speed of an internal combustion engine. The torque based engine management system (200) includes an excitation current estimation module (203) for calculating excitation curr...

This invention relates to crushable cowl side structure in vehicle to improve frontal offset crash performance comprising of a plurality of cowl side members secured to each other including outer member, inner member and top member, wherein said outer member is having a gradually reduced section from an intermediate...

The present subject matter relates to a single shaft integrated shifting system (300, 500) for selection and engagement of gears in five (5) speed manual transmission 5 along with reverse gear. The single shaft integrated shifting system (300) includes a single shift shaft (301, 501, 601) which is sliding along its ...

The present subject matter relates to a fuel pump mounting structure for restricting movement of fuel pump (204) in the fuel tank (201) during crash. The fuel pump 5 mounting structure includes a upper part (203) which is mounted at upper wall of the fuel tank (201) and a fuel pump (204) which is mounted on two axia...

The present subject matter relates to a manual transmission system for applying brake on rotating input shaft (35) of gearbox (30) during shifting of reverse gear. The manual transmission comprises a shift tower shaft (31) and a gear shift lever (38) which is mounted on the shift tower shaft (31) to shift gears, suc...

The present subject matter relates to a heat dissipating bracket (700, 1204) for covering free space (1202) available between upper lamp housing and lower lamp housing for increasing breathing air volume for lamp for better heat dissipation and prevent entry of foreign particles into the lamp. The heat dissipating b...

The present subject matter relates to a lamp assembly (600) for dissipating heat and restricting entry of foreign particles. The lamp assembly (600) comprises a cutout (501) in lower lamp housing at upper side for dissipation of heat. Further, the lamp assembly has a heat dissipating bracket (700, 902) mounted on th...

The present subject matter relates to an exhaust pipe support mounting structure for supporting an exhaust pipe (300) in a vehicle. The exhaust pipe support mounting structure includes a lower connecting member shaft (308) which is 5 mounted on the exhaust pipe (300) and an exhaust pipe mounting bracket assembly (40...

The subject matter disclosed herein relates to structure of a bracket structure 400 of tailgate hinge mounting location that can overcome tailgate inertial loads and provide strength and durability at tailgate hinge bolt location 406. The present bracket structure 400 incorporates spot welding of at least three legs...

The subject matter disclosed herein relates to lubricant oil supply system (200) in the internal combustion engine. The present lubricant oil supply system (200) has two separate lubrication circuits (201, 202) for cylinder head and cylinder block respectively. The lubrication circuits (201, 202) has oil pumps, oil ...

The subject matter disclosed herein relates to a Manual Steering Gearbox having inner ball joint assembly (200) for providing mechanical assist mechanism for steering return-ability improvement. In the present subject matter, a spring embedded steering boot (205) is provided to store elastic potential energy during ...

The subject matter disclosed herein relates to structure of Gas cylinder frame which is made of Steel tubes/pipe and Steel Sheets welded by welding to reduce tooling cost, weight. Further, the gas cylinder frame is mounted on the vehicle chassis with a C-shaped mounting bracket. The steel pipes are connected with ea...

The subject matter disclosed herein relates to a combination of structures in garnish (5.7) and garnish support (5.6) and their mountings including a door panel (5.4) to which the garnish support (5.6) is fixed; a plurality of wedge shapes (6.4) and a plurality of snap structures (4.2) integrated with the garnish (5...

The subject matter disclosed herein relates to a door handle switch assembly (400) for actuating passive entry system of vehicle and for unlatching vehicle door. The door handle switch assembly (400) has a handle frame (403) mounted inside outer panel (402) of the vehicle door and a handle gripper (401) mounted on t...

The subject matter disclosed herein relates to a hose-pipe assembly (300) with self locking mechanism. The hose-pipe assembly (300) has a pipe (302) having a wedge (304) which is provided around circumference of the pipe (302) at predetermined distance from sealing spool (305) and a hose (301) having a plurality of ...

The subject matter disclosed herein relates to a plastic part (403) having a plurality of metal plate doghouses (402) to decrease overall packaging space, i.e., gap between the styling surface and the vehicle body. The plastic part (403) has a plurality of doghouses at inner surface of the panel. Each doghouse from ...

The subject matter disclosed herein relates to lever actuated clutch system (200) in transmission of vehicle. In the present clutch system, the linkages have been removed and the system (200) is being actuated electronically by motor (14-a) with help of a lever (13) mounted on steering (12). The present system avoid...

The subject matter disclosed herein relates to a bumper (200) for a vehicle to absorb impact energy at lower leg area during the vehicle collision. The bumper (200) has an upper portion of mounted with upper cross member. The upper portion has capabilities to absorb upper leg impact. Further, the bumper (200) has a ...

The invention relates to a ventilation structure at the rear part of the passenger vehicle comprising a ventilator mounted on the vertical side of panel comp box section behind rear bumper near medium plane of the passenger vehicle; and ventilation holes on the slant surface of said panel comp box section below the ...

The invention relates to a cylinder head cover with in-built cooling circuit of length ranging from 250 mm to 400 mm and the diameter ranging from 20 mm to 30 mm for a lessor pressure drop in coolant passage wherein the proximal end of the cooling circuit, to radiator, is attached by means of connecting hose to radi...

The subject matter disclosed herein relates to a spin-on type oil filter (400) having arrangement for mounting and un-mounting from vehicle engine/stationary engine. The spin-on type oil filter (400) includes an elongated cylindrical housing (401) having closed bottom portion (401a) Further, a base plate (402) is pr...

The invention relates to a service door panel, for automotive Heating, Ventilating and Air Conditioning (HVAC) Unit, fixed or hinged on easily accessible side of the HVAC unit by means of either snap locks provided from the other adjacent side of HVAC unit or by means of gasket or sealant for locking said service do...

This invention relates to a reinforcement in automobile for reduction of vibration due to global body torsion mode comprising a single curved structure having a substantially L-section which is secured to backdoor upper corner area in weld body of vehicle. It gives rise the following advantageous features:- -Light...

The subject matter herein relates to an electrical system (200) for distribution of electrical power to warning system (212) of an emergency vehicle. The electrical system (200) includes an ignition switch (203) connected with the battery (201) via ignition (IGN) fuse (202). Further, the electrical system has an acc...

The subject matter disclosed herein relates to a multi joint hinge assembly (300) for vehicle hood to absorb pedestrian head impact force during collision of pedestrian with vehicle front. The multi joint hinge assembly (300) has a hinge arm (301) and a base component (302). The multi joint hinge assembly (300) has ...

The subject matter herein relates to a main bearing cap (200) for precise repositioning with cylinder block (300) to define a bearing bore between the main bearing cap (200) and the cylinder bock (300). The main bearing cap (200) has at least two foot portions (201, 202) provided at lateral side of a semi-circular b...

The subject matter disclosed herein relates to multi stepped windshield molding structure (400) in vehicle for improving aerodynamic drag coefficient and ORVM visibility. The present windshield molding structure (400) is designed to provide smooth air flow over windshield A-pillar junction and at the same time ensur...

The subject matter disclosed herein relates to an intake air manifold with tumble generation mechanism to improve knock resistance. In the intake air manifold (402) a ramp shape tumble generating structure (406) provided to change the air flow cross-section to generate the air flow stream so that air enters in combu...

The subject matter disclosed herein relates to a front lower energy absorber (200) for front bumper of vehicle to protect pedestrian leg during impact. The front lower energy absorber comprises an upper part (201), and a middle part (202) and the lower part (203). The front lower energy absorber has lateral beads st...

A method to manufacture a dual tone alloy wheel wherein an aluminium substrate is coated with a primary coat followed by an intermediate coatto produce a wheel surface. A graphic sticker is cut to form a desired shape from a desired color and is pasted on said wheel surface. A top coat of a clear material is applied...

The subject matter herein relates to a ferrule (203) for avoiding entry of grease into speedometer (201). The ferrule (203) is provided in between cable (204) and speedometer head (201). The ferrule (203) has a first tubular portion (203a) and a second tubular portion (203b) which are concentric with a central axis....

The subject matter disclosed herein relates to tool (700) for removing and fitting brake shoe component (1101) on brake back plate during service. The tool (700) has a clamper arm (500) and a depressor arm (600). The clamper arm (500) and the depressor arm (600) are hingedly connected with each other to define the t...

The subject matter disclosed herein relates to a compact gear shift system having compact gear shift tower for selecting and shifting gears in gearbox of vehicle. The present compact gear shift system has less number of parts which results in cost and efficiency.   To be published with Fig. 3 ...

Electrostatic discharge is the sudden flow of electricity/charge caused by a contact (either electrical short or dielectric breakdown) when differently-charged objects are brought close together. A certain materials become electrically charged after they come into frictional contact with a different material (e.g. r...

The subject matter disclosed herein relates to a method and a system for leaning fuel air mixture in internal combustion (IC) engine (15) and converting IC engine (15) emissions into allowable limits. The system is implemented in the ECU (14) which is communicatively coupled with the exhaust system of the vehicle. T...

The subject matter herein relates to a mass damper mounting assembly (500) for damping booming noise and vibrations of a vehicle. The mass damper mounting assembly (500) is mounted in between reinforcement of back door garnish (202) and door latch (203). The reinforcement is spot welded on the reinforcement of back ...

The subject matter disclosed herein relates to structure of Gas cylinder frame which is made of Steel tubes/pipe and Steel Sheets welded by welding to reduce tooling cost, weight. Further, the gas cylinder frame is mounted on the vehicle chassis with a C-shaped mounting bracket. The steel pipes are connected with ea...

The subject matter disclosed herein relates to a dash side panel structure (400) for absorbing impact force during front vehicle crash. The dash side panel structure (400) has upper part, middle part, and lower part. The upper part (401) has a rectangular bent profile (401a) at lower portion with a flange (401b). Th...
